Power Electronics and Circuit Network Laboratory
Name of Lab
Power Electronics and Circuit Network Laboratory
Lab In charge
Shri. Deodatta Y. Shingare
Lab Technician
Mr. Arun S. Rawate
Lab Area
66 m2
Lab Total Investment
Rs. 2,28,604/- (Approx.)
Equipment Details
| Sr. No. | Major Equipment | Cost in Rs. |
| 1. | Regulated DC power supply (0-30V), (0-5A) (5 nos.) | 19,960/- |
| 2. | Theorem Kits: KCL, KVL, Thevenin’s Theorem, Norton’s Theorem, Max. Power Transfer Theorem etc. | 6,469/- |
| 3. | Tubular Rheostat: (750W, 1.2A) (4 nos.) | 8,617/- |
| 4. | Tubular Rheostat: (500W, 1.8A) (3 nos.) | 7,097/- |
| 5. | Tubular Rheostat: (35W, 5A) (2 nos.) | 3,435/- |
| 6. | DC Ammeters: (0-5A) (2 nos.) | 2,587- |
| 7. | DC Voltmeter: (0-15-30-75V) (3 nos.) | 4,218/- |
| 8. | A.C. Milliammeters: | 12,213/- |
| 9. | (0-50mA), (0-100mA), (0-250mA) (3 nos. each) | 4,550/- |
| 10. | AC Ammeters: (0-5-10A) (2 nos.) | 4,550/- |
| 11. | AC Voltmeters: (0-150-300-600V) (2 nos.) | 47,600/- |
| 12. | Digital Storage Oscilloscopes: 50 MHz, Dual trace (2 nos.) | 7,800/- |
| 13. | Single-phase Auto transformer: 1KVA, 10A (2 nos.) | 22,050/- |
| 14. | 3-Ph Auto-transformer: 415V, 20A | 4,108/- |
| 15. | Variable Inductor: 5A | – |
| 16. | Power Electronics Trainer Kits | 19,960/- |
